流量计算器

使用我们的流量计算器,您可以根据管道的内径和公称直径确定流速、流量和压力损失。

流速必须根据管道的预期用途进行近似。

流速的标准值为:
v = 0.5 - 1.0 m/s 在吸入侧
v = 1.0 - 3.0 m/s 在压力侧

要使用内径和适用的SDR查找外径,请使用以下公式:

Formula

d = di · SDR SDR - 2

Please accept all cookies to view the external content.

Units
Metric
Inner Diameter [mm]
4


Flow Velocity [m/s]
0.1
Flow Rate
l/min0.08
m3/h0
gpm (US gallons)0.02
gpm (British gallons)0.02
Pipe Length [m]
1
Pressure Loss
bar0
