COOL-FIT PE Plus

A maintenance-free pre-insulated plastic piping system for your glycol, brine and chilled water loop.

COOL-FIT® PE Plus is a cutting-edge technology, designed for use in commercial and industrial refrigeration installations. It pairs corrosion and maintenance-free components with ex-works pre-insulation in a system that is reliable and efficient. Safe, lightweight and quick to install, this system is ideally suited for fruit and vegetable processors, slaughterhouses, and breweries. With COOL-FIT PE Plus, users can operate with maximum efficiency and no interruptions while minimizing maintenance and operating costs.

Size Range:

d32-d450 (1" - 18")

Pressure Rating:

150 PSI SDR 17

Operating Temperature:

-58°F to 140°F (-50°C to 60°C)

Materials:

Carrier Pipe: GF PE100 HDPE
Outer Jacket Pipe: GF PE100 HDPE
Outer Jacket Fittings: Polyurethane Low Density(PUR)
Foam Insulation: Polyurethane High Density(PUR)

100% maintenance-free and reliable

The plastic design eliminates the risk of corrosion and smooth inner surfaces prevent deposits, making the system virtually maintenance-free and as efficient as it was on its first day of operation.

65% less weight

Much lighter than metal piping systems, COOL-FIT® PE Plus lowers structural demands on buildings and supporting structures while reducing the need for heavy and expensive transport aids.

50% faster installation

Consisting of pre-insulated components that require no extra modifications, COOL-FIT® PE Plus takes advantage of electrofusion installation to allow for rapid set-up.

Higher energy efficiency

The low thermal conductivity of the plastic paired with the highly efficient foam increase the system’s energy efficiency, which in turn cuts energy costs.
