Meet our New Heroes as they encompass all the qualities you have come to expect from the MULTI/JOINT® 3000 Plus present in the water and gas market for more than 30 years. With impressive new sizes in ranges – DN900, DN925, DN1000, and DN1025 – the MULTI/JOINT® is one of the largest pull-out resistant fittings for water applications on the market. The new fittings come with a lifespan of 50 years, which is a known property of the entire MULTI/JOINT® family, promising a lasting solution for your needs. Much like legendary heroes, they are prepared for the long haul, providing strength, remarkable flexibility and unwavering support in water applications. In essence, they are big, red and strong.
Big
Explore the New Heroes in larger dimensions including DN900, DN925, DN1000 & DN1025 for water applications up to 10 bar.
Welcome the wide-ranging capabilities of MULTI/JOINT® 3000 Plus, where the 'one-size fits and grips all' approach adapts seamlessly to different pipe materials and diameters, allowing you to streamline stock management and resource utilization. MULTI/JOINT® is suitable for various pipe materials, including AC, PE, PVC(O), GRP, (stainless) steel, (ductile) cast iron, and more, showcasing its true versatility.
Red
Our new MULTI/JOINT® 3000 Plus line extension is coated with the well-known red Resicoat® epoxy powder. This high-quality epoxy powder coating on ductile iron components guarantees lasting reliability and robust connections. The finishing is corrosion-proof and approved by GSK. (GSK=The German Quality Assurance Association for Heavy-Duty Corrosion Protection)
Strong
The restraint fittings are suitable for applications in water up to 10 bar and the non-restraint connections are designed for water pressure up to 16 bar. With a remarkable life expectancy of 50 years, our pipe connection system provides safe and reliable connections to ensure your peace of mind.
Benefits
Installation video for bigger dimensions
Please accept all cookies to view the youtube video content.
Technical details
Type
Description
Range 1
Range 2
| Type | Description | Range 1 | Range 2 |
| Coupling | DN900 | 899 - 931 | 899 - 931 |
| Coupling | DN925 | 939 - 971 | 939 - 971 |
| Coupling | DN1000 | 994 - 1026 | 994 - 1026 |
| Coupling | DN1025 | 1042 - 1074 | 1042 - 1074 |
| Reduced Coupling | DN925 x DN900 | 939 - 971 | 899 - 931 |
| Reduced Coupling | DN1025 x DN1000 | 1042 - 1074 | 994 - 1026 |
| Flange adaptor | DN900 | 899 - 931 | 900FL |
| Flange adaptor | DN1000 | 994 - 1026 | 1000FL |
| Reduced flange adaptor | DN925 x DN900FL | 939 - 971 | 900FL |
| Reduced flange adaptor | DN1025 x DN1000FL | 1042 - 1074 | 1000FL |
More technical details
- Flange drilling: PN10 / PN16
- Pressure: 10 bar restraint / 16 bar non restraint
- Angularity: 8 degrees per socket side
- Gasket: EPDM or NBR
- Bolts/nuts/washers: A4 (AISI 316)
