PUR-SplitTube™

PUR-SplitTube™ is pipe insulation that's quickly and easily installed in the field utilizing 6.1m (20-foot) long polyurethane shells with a hinged polyethylene jacket.

Show Products Order Now

PUR-SplitTube™ is an innovative pipe insulation solution designed for quick and easy installation in the field. With its unique hinged polyethylene jacket and 6.1 m (20 ft) long polyurethane shells, PUR-SplitTube™ offers a superior insulation value, high compressive strength, and effective closed cell construction that significantly reduces heat loss and gain. This product can be applied to any direct bury piping applications ranging from 25 mm (1 in) to 350 mm (14 in), and supports temperature applications up to 93°C (200°F), making it ideal for electrical heat tracing.

Size Range:

25 mm (1 in) to 350 mm (14 in)

Operating Temperature:

93°C (200°F)

Materials:

Polyethylene jacket and polyurethane shells

Features
Video
Portfolio
Applications
Downloads

Features & Benefits

Features & Benefits

Few seams relative to conventional mechanical insulation shells resulting in water tight system with less heat loss/gain overall. Lightweight and easy to ship. Broad temperature range to 200° F continuous, and up to 300° F with high temp version.

System range: 25 mm to 350 mm (1” to 14”)
Max insulation value
High compressives
Closed cell construction
Lightweight and easy to ship
Applications up to 93°C (200°F) or 149°C (300° F)
Compatible with electric heat tracing

Speed of Installation

PUR-SplitTube™ is a simple clam shell system that installs far quicker than comparable systems as a result of the hinged jacket and peel-away closure design

Fast Delivery to Site

PUR-SplitTube™ can be shipped to the site in a number of days (not weeks).

Installation Value

PUR-SplitTube™ is constructed of high quality, lightweight polyurethane foam providing maximum insulation value, high compressive strength, and closed cell construction to provide moisture resistance.

Very Few Seams

PUR-SplitTube™ has fewer seams than conventional mechanical clam shell type systems, resulting in a tighter overall system with less thermal bleed.

Installation Value

Super fast installation using “hinged” jacket and peel-away closure.

Closed Cell Construction

PUR-SplitTube™ offers few seams relative to conventional mechanical insulation shells resulting in a water tight system with less heat loss/gain overall. Great for directional drill applications.
